OSTARA

Air Quality Monitoring Station

OSTARA is an air quality measurement station designed for the outdoors, especially harsh environments.

Boasting on-site installation and autonomous operation, the OSTARA station measures the main air pollutants, calculates environmental indicators, and collects meteorological information:

  • Fine particulate matter: PM 1, PM 2.5, PM 10
  • Odours and certain gases: carbon monoxide, hydrogen sulphide, ammonia, nitrogen dioxide, oxygen, ozone, sulphur dioxide, organo-volatile compounds (other gases on request)
  • Environmental indicators: freezing point, dew point, windchill, humidex, air quality index (ATMO), Cote Air Santé (CAS)
  • Meteorological information: temperature, atmospheric pressure, relative humidity.

The station is also equipped for global air and water monitoring via auxiliary sensors:

  • WiMo probe to measure physicochemical water parameters, such as temperature, pressure, conductivity, turbidity, pH, etc.
  • Ultrasonic anemometer to measure wind speed.

Applications

Perfect for any site requiring air quality monitoring due to particulate and gas emissions, including:

  • Mines
  • Quarries
  • Oil and natural gas refineries
  • Aluminum smelters, steel mills
  • Petrochemical plants
  • Industrial boilers and furnaces
  • Pulp and paper plants
  • Foundries
  • Electric power plants
  • Construction sites
  • Ports and coastal areas
  • Urban environments...

Main benefits

  • Flexible installation: posts, walls, fences (brackets supplied)
  • Power supply: stand-alone solar (solar panel & battery) or mains backup
  • Wireless (WiFi) configuration and measurement display: intuitive, easy-to-use web interface
  • E-mail and SMS monitoring and alerts
  • Secure data transmission (cellular telemetry)
  • Extended monitoring (air, water, etc.) capacity: WiMo probe, anemometer, other sensors on request
  • Automatic sensor recognition
  • Robustness: corrosion-resistant material, quality connectors, IP66 enclosure
  • Gas sensors fitted with anti-particulate protective membrane (on-site, toolless replacement possible)
  • Integrated calculation of regulatory air quality indicators (ATMO, CAS/AQHI)
  • Range of intelligent & Plug'nPlay gas sensors, temperature-compensated, easy to install anywhere in the station
  • Rich, user-friendly, Inoview operating platform
  • GNSS positioning (site geolocation, theft protection)

Specifications

AVAILABLE SENSORS AND MEASUREMENTS
See "OSTARA - RANGE OF SENSORS" PDF below in Documents section.

PHYSICAL SPECIFICATIONS

  • Dimensions: W = 300 x D = 210 x H 485mm
  • Tightness IP66
  • Impact resistance IK10
  • Weight: 5 kg (without battery)

MECHANICAL SPECIFICATIONS

  • Fibreglass-reinforced polyester
  • Class II insulation
  • Corrosion resistance
  • Wall or pole mounting

COMMUNICATION

  • Cellular measurement transmission: FTP/SMTP 2G/3G/4G LTE
  • E-mail and SMS alerts
  • Local wireless access (WiFi); integrated web interface for parameter setting and data viewing (phone, tablet, laptop)
  • ModBus digital communication with external instruments and sensors
  • Ethernet communication

TEMPERATURE

  • Operating temperature: -20 °C / +55 °C
  • Storage temperature: 0 °C / + 40 °C

POWER SUPPLY

  • Stand-alone solution: solar panel + support + lead battery
  • External power supply solution: with battery backup
